What Do Our Part Numbers Mean?

The part numbers for our tubing and hose products are designed to follow a pattern that helps to identify the family of products and different aspects of their construction.



The first two letters identify the part as an AdvantaPure product. The following letter identifies the material that the core or I.D. of the product is made of. The letters that follow are used to describe the construction of the product. The numbers that follow indicate the size of the inner diameter and outer diameter. The following is an example of part number APAF-BP-0125-0250

Part Number explained

Below is a listing of AdvantaPure tubing and hose part number families with descriptions.

APST Silicone, Platinum-Cured Tubing, Unreinforced
APHP Silicone, Platinum-Cured, High Pressure Tubing, Unreinforced
APSH-P Silicone, Platinum-Cured Hose – Polyester Braid Reinforced
APSH-DB Silicone, Platinum-Cured Hose – Polyester Double-Braided Reinforced
APSW-SP Silicone, Platinum-Cured, Wire Reinforced, Spiral Mandrel-Wrapped 4-ply – Polyester Mesh Fabric, Smooth O.D. Suction Hose
APSW-SPC Silicone, Platinum-Cured, Wire Reinforced, Spiral Mandrel-Wrapped 4-ply – Polyester Mesh Fabric, Convoluted O.D. Suction Hose
APFOS-W Fluoropolymer (PTFE), Overbraided Stainless Steel – White Core, Smooth I.D.
APFOS-WC Fluoropolymer (PTFE), Overbraided Stainless Steel – White Core, Convoluted I.D.
APFOSJ-W Fluoropolymer (PTFE), Overbraided Stainless Steel – Silicone Jacketed – White Core, Smooth I.D.
APFOSJ-WC Fluoropolymer (PTFE), Overbraided Stainless Steel – Silicone Jacketed – White Core, Convoluted I.D.
APEWF-W EPDM Rubber, Stainless Steel Wire Helix Reinforced, Food Grade – White Core, Smooth I.D.
APAF-BP AdvantaFlex®, BioPharmaceutical Grade TPE Tubing, Unreinforced

Contact your AdvantaPure representative for more info 1-888-755-4370
